Marantz Model 30 Integrated Amplifier

The Marantz Model 30 Integrated Amplifier outputs 100 watts per channel into 8 ohms, driving demanding stereo loudspeakers with authoritative control and acoustic clarity.

Pure Analogue Architecture:

The Marantz Model 30 features a discrete, two-stage layout that completely isolates the preamplifier and power amplifier sections. By housing these stages independently and providing separate power supplies, signal paths remain shielded from electronic noise, resulting in expansive soundstages, precise instrument placement, and rich tonal warmth.

Custom Marantz HDAM Circuitry:

Equipped with Hyper Dynamic Amplifier Modules (HDAM-SA3), the Marantz Model 30 replaces standard integrated circuits with discrete component boards. This architecture achieves rapid signal response and wide dynamic range, bringing lively presence and natural musicality to high-resolution tracks and vinyl recordings alike.

Marantz Musical Premium Phono EQ:

Vinyl playback is elevated through a specialised phono stage designed for both Moving Magnet (MM) and Moving Coil (MC) cartridges. Featuring a built-in MC input impedance selector with low, mid, and high settings, the Marantz Model 30 allows listeners to match specific cartridges effortlessly without external step-up transformers.

Precision Build & Vibration Damping:

Constructed with thick aluminum front panels, a double-layered bottom plate, and rigid isolation feet, the Marantz Model 30 suppresses external vibrations before they reach sensitive audio circuitry. The central porthole display and tactile rotary dials deliver an intuitive interface rooted in classic Marantz heritage.

Authorized Dealer:

We are an authorized dealer for Marantz, ensuring your investment receives dedicated customer support and long-term peace of mind. Purchasing from an authorized dealer confirms that you receive the full manufacturer's warranty alongside direct guidance for building an unforgettable home audio environment.

Key Features & Listener Benefits:

• 100 Watts Per Channel at 8 Ohms: Delivers clean, high-current output to drive a wide variety of stereo speakers with effortless authority.
• Custom HDAM-SA3 Technology: Provides fast transient response and wide bandwidth for clear, dynamic sound reproduction.
• Two-Stage Discrete Layout: Isolates the preamp and power sections to eliminate cross-circuit interference.
• Marantz Musical Premium Phono Stage: Offers dedicated MM and MC cartridge inputs with three impedance settings for pristine record playback.
• Solid Aluminum Front Panel & Chassis: Resists mechanical vibration while maintaining thermal stability.
• Power Amp Direct & Pre-Out Terminals: Allows versatile system configuration with external processors or standalone power amplification.

Technical Specifications:

• Rated Power Output: 100 W + 100 W (8 Ω, 20 Hz – 20 kHz, 0.07% THD); 200 W + 200 W (4 Ω, 1 kHz, 0.7% THD)
• Amplifier Topology: Class D Power Output Stage with Discrete HDAM Preamplifier
• Frequency Response: 5 Hz – 50 kHz (±3 dB)
• Total Harmonic Distortion (THD): 0.005% (1 kHz, 50 W, 8 Ω)
• Damping Factor: 500 (8 Ω, 20 Hz – 20 kHz)
• Phono Input Sensitivity: MM: 2.3 mV / 39 kΩ; MC: 250 μV (Low: 33 Ω, Mid: 100 Ω, High: 390 Ω)
• Signal-to-Noise Ratio: Phono MM: 88 dB; Phono MC: 75 dB; CD/Line: 107 dB
• Tone Controls: Bass (50 Hz, ±10 dB), Treble (15 kHz, ±10 dB)
• Analogue Audio Inputs: 5 RCA line-level pairs, 1 Phono MM/MC pair, 1 Power Amp Direct in
• Audio Outputs: 1 Stereo Pre-Out, 1 Audio Out (Recorder), 1/4" (6.35 mm) Headphone Jack
• Speaker Terminals: Custom Marantz SPKT-100+ high-purity brass binding posts
• Power Consumption: 130 W (Standby: 0.2 W)
• Dimensions (W x H x D): 443 x 130 x 431 mm
• Weight: 14.8 kg
